FEATURES:
- Battery operated, factory calibrated Class II Laser enables accurate alignment of blade and cutting line
- Large cutting capacity in a compact design and less weight
- Powerful 1,430 W direct drive motor requires less maintenance and delivers 4,300 RPM
- Miters 0° – 47° left and 0° – 60° right, with positive stops at 0°, 15°, 22.5°, 31.6°, 45° (left and right)
- Cuts up to 305 mm (12”) at 90° and 215 mm (8-1/2”) at 45°
INCLUDES:
Carbide-Tipped Saw Blade, Vertical Vise, Socket Wrench, Triangular Rule, Dust Bag, Holder Assembly
SPECIFICATIONS:
| Continuous Rating Input | 1,430W |
| Blade Diameter | 255 – 260 mm (10 – 10-1/4″) |
| Miter Angle | 47° L / 60° R |
| Bevel Angle | 45° L / 45° R |
| Max Cutting Capacity | 90°: 91 x 305 mm (3-5/8″ x 12″) |
| 45°: 91 x 215 mm (3-5/8″ x 8-1/2″) | |
| No Load Speed (RPM) | 4,300 |
| Sound Pressure Level | 97 dB(A) |
| Sound Power Level | 103 dB(A) |
| Vibration Level | 2.5 m/s² or less |
| Dimensions (L x W x H) | 825x536x633 mm (32-1/2″x21-1/8″x25″) |
| Net Weight | 20.6 kg (45.4 lbs) |
| Power Supply Cord | 2.5 m (8.2 ft) |
